Description
Specification parameter editing broadcast
motherboard chip
Chipset Description
Powered by Intel Z97 chipset
Display chip
CPU built-in display chip (requires CPU support)
audio chip
Integrated Realtek ALC1150 8-channel audio chip
network card chip
Onboard Intel I218V Gigabit LAN, Realtek RTL8111GR Gigabit LAN [1]
Detailed parameter editing broadcast
Processor Specifications
CPU type
Core i7/i5/i3/Pentium/Celeron
CPU socket
LGA 1150
Memory Specifications
memory type
4 x DDR3 DIMMs
Maximum memory capacity
32GB
memory description
Support dual channel 1866/1600/1333MHz memory
storage expansion
PCI-E standard
PCI-E 3.0
PCI-E slot
3×PCI-E X16 graphics card slots, 3×PCI-E X1 slots
storage interface
6×SATA III interface, 1×SATA Express interface
I/O interface
USB interface
6×USB3.0 interface (2 built-in +4 backplane), 8×USB2.0 interface (4 built-in +4 backplane)
video interface
1×Display Port interface, 1×HDMI interface
Power interface
One 8-pin, one 24-pin power connector
Other interfaces
2 x RJ45 network interface, audio interface, 1 x optical fiber interface
plate type
main board type
ATX form factor
Dimensions
30.5×24.4cm
software management
BIOS performance
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.8, ACPI 5.0, Multilingual BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 I Favorites, Quick Notes, History Records, F12 Quick Screenshots, F3 Shortcuts, Memory SPD Information
Other parameters
Multi-graphics technology
Support NVIDIA SLI two-way crossfire technology
Supports AMD CrossFireX hybrid technology
power supply mode
8+2 phase
RAID function
Support RAID 0, 1, 5, 10
